Versatile Video Walls

ATEN’s KE Matrix Management Software allows you to create custom video walls with up to 8 x 8 displays in
various configurations, providing flexible, scalable installations with predefined display content that is easy to
schedule.

Single Source
A source from a single transmitter can be cropped into sections for flexible display configurations:

or ....up to 8x8

Multiple Sources
Multiple sources from multiple transmitters offer unlimited combinations:

Source by TX1 Source by TX3

Source by TX2 Source by TX4

Video Wall Synchronization
The KVM over IP Matrix System’s multicast functionality means it is able to broadcast packets. When the network
switch receives the packets, it simultaneously sends them to all of the designated KE devices in the installation
for display:

KE Receiver
Scaling

Scaling

Broadcasting
KE Receiver
KE Receiver
KE Transmitter

Scaling

Scaling
KE Receiver
